NexusDrive Core 9 – 9 Nm Direct Drive Wheel Base, 21-Bit Encoder, Aluminium Housing, Smart Cooling
Delivery expect 4-8 business days.
NexusDrive Core 9: overview
The NexusDrive Core 9 is a 9 Nm direct drive wheel base for racers who take their performance seriously.
A high-performance 18-slot/16-pole servo motor and a 21-bit magnetic encoder deliver ultra-smooth, highly detailed force feedback, refined by the latest algorithm with enhanced dynamic effects.
An aviation-grade aluminium housing keeps it light and tough, intelligent temperature control with active cooling keeps it consistent, and an industrial slip ring powers wheels with no cable to twist.
Who the nexusDrive Core 9 is for
Drivers stepping into direct drive:
- Desk racers
- All disciplines
- Upgraders from gear and belt wheels
Features in detail
9 Nm
Detailed direct drive.
21-bit encoder
2,097,152 steps.
Smart cooling
Monitoring and active cooling.
Slip ring
No twisting cables.
Ecosystem hub
Pedals, dash, shifter, handbrake, E-stop.
Compatibility
Platform: PC. Titles include iRacing, Assetto Corsa, Assetto Corsa Competizione, Le Mans Ultimate, the F1 series, Forza Motorsport, DiRT Rally 2.0 and EA SPORTS WRC.
Wheels: the NexusWheel range on the Core quick release.
Mounting: 4-hole bottom mount; optional table clamp and side mounting.
Building a sim racing or flight setup
Base, rim and pedals. In a modular setup the wheel base holds the force feedback motor, the rim clips on with a quick release and the pedals connect to the base or by USB. Rims and pedals must suit your base, and the base decides which platforms are supported.
Direct drive. Direct drive bases attach the rim straight to the motor for the most detailed and strongest feedback. They need a rigid cockpit or a strong desk mount.
Load cell pedals. A load cell brake measures pressure, not travel, like a real car. It is the single upgrade that improves lap-time consistency the most.
Setup and use
- Bolt the base to a rig or fit the table clamp.
- Fit a NexusWheel.
- Connect power, pedals and USB.
- Tune force feedback in the configuration software for PC and the mobile app.
Care and maintenance
Keep the vents clear; update the firmware regularly.
Specifications
| Torque | 9 Nm peak |
| Encoder | 21-bit magnetic |
| Rotation | 90–2700° |
| Peak power | 180 W |
| USB rate | 1000 Hz |
| Motor | 18-slot / 16-pole servo |
| Size | 240 x 157 x 124 mm |
| Housing | Aviation-grade aluminium |
What's in the box
- NexusDrive Core 9 wheel base
- Power adapter
- USB cable
- Toolkit
- User manual
Shipping, returns and warranty
Shipping
Shipping is free on orders worldwide. Orders are prepared and dispatched within 1–3 business days and typically arrive within 4–8 business days in total, with tracking sent by email. Large items such as cockpits, seats and monitor stands can ship in several boxes, customs or public holidays can occasionally add a few days, and some items ship directly from our supplier.
Returns
You have 14 days from delivery to return the product for a refund, for any reason. It must be new, unused and in its original packaging with all accessories and documents. Contact us at metanexusxr@gmail.com with your order number to start the return.
Warranty
Products bought from our store are covered by a 2-year limited warranty against manufacturing defects. If anything goes wrong, email us your order number and a short description or photo and we will handle the claim with you.
Frequently asked questions
What makes it better than entry wheels?
Direct drive detail and a 21-bit encoder.
Can I use it on my existing rig?
Yes, it bottom-mounts with 4 bolts.
Is a steering wheel included?
No, the base only; see our NexusDrive bundles.
How long does delivery take?
Shipping is free worldwide. Orders are dispatched within 1–3 business days and usually arrive within 4–8 business days in total, with tracking by email.
Can I return it if it is not right for me?
Yes, within 14 days of delivery, as long as it is new, unused and in its original packaging. Email metanexusxr@gmail.com with your order number to start a return.
Is it covered by a warranty?
Yes, a 2-year limited warranty against manufacturing defects on products bought from our store.
See all our direct drive wheel bases or the 12 Nm Core 12, or browse the complete sim racing range to build your rig.
