NexusPedal Hydraulic EVO – Dual-Stage Hydraulic 3-Pedal Set, 200 kg Brake & Built-In Haptics
€1,798.00
Delivery expect 4-8 business days.
NexusPedal Hydraulic EVO: overview
The NexusPedal Hydraulic EVO is our top hydraulic pedal set. Dual-stage hydraulic cylinders with front and rear preload fine-tuning let you set braking bias exactly, and a 20 MPa (about 200 kg) sensor reads every input precisely.
Every pedal is adjustable: throttle travel and force, clutch spring preload and bite-point force, brake front/rear preload – plus pedal spacing, surface angle, panel height and footrest position.
A built-in vibration module adds real-time haptics with native support for iRacing and SimHub, and the whole set is CNC-machined 6061-T6 aluminium, sandblasted and anodised.
Who the nexusPedal Hydraulic EVO is for
Drivers who want the best hydraulic feel:
- Esports competitors
- Professional training simulators
- iRacing drivers who want pedal haptics
Features in detail
Dual-stage hydraulics
Front and rear preload fine-tuning for adjustable braking bias.
20 MPa sensor
About 200 kg, high precision.
Built-in haptics
Vibration feedback with native iRacing and SimHub support.
Full adjustment
Throttle travel/force, clutch preload/bite point, brake preload, spacing, angle, height, footrest.
6061-T6 aluminium
CNC-machined, sandblasted and anodised.
Direct USB
Out of the box, with future CAN support.
Compatibility
PC via USB; mounts on our NexusRig pedal plates, inverted mounts and most cockpits.
Building a sim racing or flight setup
Base, rim and pedals. In a modular setup the wheel base holds the force feedback motor, the rim clips on with a quick release and the pedals connect to the base or by USB. Rims and pedals must suit your base, and the base decides which platforms are supported.
Direct drive. Direct drive bases attach the rim straight to the motor for the most detailed and strongest feedback. They need a rigid cockpit or a strong desk mount.
Load cell pedals. A load cell brake measures pressure, not travel, like a real car. It is the single upgrade that improves lap-time consistency the most.
Setup and use
- Mount the pedals and set spacing, angle and height.
- Connect USB.
- Calibrate and set preloads and bite point in software.
- Enable haptics in SimHub or iRacing.
Care and maintenance
Check mounting bolts regularly; keep the hydraulics clean; never open the hydraulic circuit.
Specifications
| Hydraulics | Dual-stage cylinders, front and rear preload |
| Brake sensor | 20 MPa (~200 kg) |
| Haptics | Built-in vibration module (iRacing, SimHub) |
| Material | CNC 6061-T6 aluminium, sandblasted and anodised |
| Adjustment | Travel, force, preload, bite point, spacing, angle, height, footrest |
| Connection | USB (CAN support planned) |
What's in the box
- 3-pedal hydraulic set
- Cable and accessories as supplied
Shipping, returns and warranty
Shipping
Shipping is free on orders worldwide. Orders are prepared and dispatched within 1–3 business days and typically arrive within 4–8 business days in total, with tracking sent by email. Large items such as cockpits, seats and monitor stands can ship in several boxes, customs or public holidays can occasionally add a few days, and some items ship directly from our supplier.
Returns
You have 14 days from delivery to return the product for a refund, for any reason. It must be new, unused and in its original packaging with all accessories and documents. Contact us at metanexusxr@gmail.com with your order number to start the return.
Warranty
Products bought from our store are covered by a 2-year limited warranty against manufacturing defects. If anything goes wrong, email us your order number and a short description or photo and we will handle the claim with you.
Frequently asked questions
How is it different from the Lite?
Dual-stage hydraulics, a 200 kg sensor and built-in haptics.
Do the haptics need extra hardware?
No, the vibration module is built in.
Which sims support the haptics?
iRacing natively and others through SimHub.
How long does delivery take?
Shipping is free worldwide. Orders are dispatched within 1–3 business days and usually arrive within 4–8 business days in total, with tracking by email.
Can I return it if it is not right for me?
Yes, within 14 days of delivery, as long as it is new, unused and in its original packaging. Email metanexusxr@gmail.com with your order number to start a return.
Is it covered by a warranty?
Yes, a 2-year limited warranty against manufacturing defects on products bought from our store.
